CDL Air Brakes Test Numbers You Must Memorize
Search for the air brakes PSI numbers online and you'll find a different answer on almost every page. One site says cut-out is 125 PSI. Another says 120 to 140. A third says spring brakes pop out at 20 to 40 PSI, while another says 20 to 45. This isn't because everyone is wrong — it's because some numbers are federally fixed and others vary by vehicle and state manual. This guide gives you every number, explains exactly which ones are fixed and which ones vary, and includes a flashcard drill so they actually stick before test day.
The one number that never changes: The low air warning must activate at or before 60 PSI on every CDL test in every state. It's a federally mandated safety minimum. Almost every other number on this page has a range — memorize the range, then confirm the exact figure in your state's manual before test day.
Every PSI number in one place
Why the numbers don't all agree — and which ones to trust
This is the part almost every other guide skips, and it's the reason you see conflicting numbers everywhere. Not every PSI figure on the air brakes test comes from the same source.
📐 Fixed by federal regulation (memorize the exact number)
Low air warning — 60 PSI. Federal Motor Vehicle Safety Standards require the warning device to activate at or before this point on every air brake system, in every state. There is no acceptable range here — 60 PSI is the ceiling, and the device must trigger at that pressure or higher.
⚙️ Set by vehicle manufacturer (expect a range)
Governor cut-out and cut-in. These are configured by the truck manufacturer within a federally allowed range, which is why you'll see 120–140 PSI on some manuals and 100–125 on others — both are correct for different vehicles. Your state CDL manual will give you the specific range used on your test.
📋 Set by state manual (check your specific state)
Spring brake pop-out point. Most manuals cite 20–45 PSI, some say 20–40. The difference is small but real — always verify against your own state's manual rather than memorizing a number from a generic source.
The single biggest mistake: Memorizing PSI numbers from a study site for a state other than the one you're testing in. The core concepts are the same everywhere, but the exact figures examiners expect can differ. Always cross-check against your own state's official CDL manual before test day — we've covered state-specific air brake details for Texas, California, and several other states if you're testing in one of those.
Drill the numbers — flashcard practice
Reading a table once won't make these numbers stick. Active recall — testing yourself instead of re-reading — is what actually works. Tap the card to flip it, then use the buttons to move through the deck.
🎯 Air Brake PSI Flashcards
Tap the card to reveal the answer. Work through all 8 before moving on.
Brake lag — the number most people forget entirely
This figure doesn't get asked about as often as the PSI numbers, but it shows up in scenario questions and matters just as much on the road. Brake lag is the time it takes for air to travel from the pedal to the brake chambers after you press it.
- Typical brake lag: Approximately 0.4 seconds on a well-maintained system.
- Distance added at 55 mph: Roughly 32 feet — on top of normal reaction time and braking distance.
- Why it's tested: Scenario questions often ask why following distance requirements are longer for air-brake vehicles than passenger cars. Brake lag is part of the correct answer, alongside the vehicle's overall weight and stopping distance.
The in-cab check sequence — where the numbers actually get used
Memorizing numbers in isolation only gets you halfway. The test — and the real-world inspection — asks you to use them in a specific order. Here's where each number fits into the sequence.
- Build air pressure to governor cut-out — start the engine and let pressure climb to the cut-out point (typically 120–140 PSI), then confirm the compressor stops.
- Check for leaks with the engine off — release the brakes and watch the gauge for 1 minute. Loss should not exceed 3 PSI (single vehicle) or 4 PSI (combination vehicle).
- Fan the brakes down to the low air warning — apply and release the pedal repeatedly. The warning light and buzzer must activate at or before 60 PSI.
- Continue fanning until spring brakes apply — keep reducing pressure. Spring brakes should engage automatically somewhere in the 20–45 PSI range.
- Rebuild pressure and run the applied leak test — bring pressure back to cut-out, apply the brake pedal firmly, and hold for 1 minute, watching for excess leakage.
For the complete walkthrough of every inspection step — not just the numbers — see the full CDL Air Brakes Test Explained guide, which covers the entire pre-trip sequence in order.
Memory trick that actually works: Say the sequence out loud as one continuous phrase — "Build to cut-out, leak test under 3, fan to 60 for the warning, fan to 20-45 for spring brakes, rebuild and leak test again." Repeating the full chain out loud five times links the numbers to the order, which is exactly how the examiner will be scoring you.
How these numbers connect to your endorsement
If you're going Class A, you'll also need the Combination Vehicles knowledge test, which builds on these same air brake numbers — particularly how dual air systems and trailer air supply lines interact. If hazmat or tanker hauling is part of your plan, the air brake check stays identical, but you'll add separate knowledge tests on top of it. See CDL Endorsements: Complete List and Guide for how air brakes fits into the bigger picture, and How Many Questions Are on the CDL Test? for exactly how many questions the Air Brakes section adds to your total.
Want the structured version of all this?
PassMyCDL's free lessons cover the full air brakes section with video walkthroughs of every PSI number and the in-cab check sequence — no account needed.
Air Brakes Numbers — FAQ
What PSI does the governor cut out at?
Typically 120–140 PSI on most modern trucks, though some manuals list 100–125 PSI depending on the vehicle. Confirm the exact figure in your state's CDL manual since it's commonly tested.
At what PSI must the low air warning activate?
At or before 60 PSI — this is consistent across virtually every state manual since it's a federally mandated safety minimum, not a vehicle-specific setting.
At what PSI do spring brakes pop out?
Somewhere between 20 and 45 PSI, depending on the vehicle and manual — some sources cite 20–40 PSI. Check your specific state's manual for the exact figure used on your test.
Why do air brake PSI numbers vary between sources?
Some numbers, like the 60 PSI low air warning, are fixed by federal regulation. Others, like governor cut-out and spring brake pop-out, are set within an allowed range by the vehicle manufacturer and vary slightly by state manual.
What is the air leak test limit?
With the engine off and brakes applied, pressure should not drop more than 3 PSI per minute on a single vehicle or 4 PSI per minute on a combination vehicle. Exceeding these limits indicates a leak and fails the inspection.
